ED3600A / ED4600A / ED5000A
ADAYO
ADAYO Lessing Hybrid Solar Inverter 3.6 KW /4.6 KW /5KW is a typical on-grid and off-grid solar inverter product series. It is usually connect with the PA05G,PA05S wall pack batteriesto build a solar power station.
ADAYO Lessing hybrid inverter power ranges from 3.6kW, 4.6kW to 5kW. With a built-in MPPT charger, this inverter series has multiple modes. It is the core component of the solar energy storage system.
The Lessing hybrid inverter is single phave and with full certificate for Europe market, the main features as follow:
Multiple operating modes,on-grid,off-grid and UPS.MPPT control.
Compatible with almost all 24V/48VLiFePO4 battery pack and lead-acid battery.
Integrated smart APPcan remotely diagnose and update.
One key to reactive the LiFePO4 batterypack/pre-charge the input stage.
Frequency droop control,Max. 6pcs parallel.DC couple and AC couple to retrofit existingsolar system.
Model | ED3600A | ED4600A | ED5000A |
Battery Input Data | |||
Battery Type | Lithium / Lead-Acid | ||
Nominal Battery Voltage (V) | 51.2 | 51.2 | 51.2 |
Max.Continuous Charging Current (A) | 80 | 95 | 95 |
Max. Continuous Discharging Current (A) | 85 | 100 | 100 |
PV String Input Data | |||
Max.Input Power (W) | 5200 | 6600 | 7000 |
Max.Input Voltage (V) | 500 | 500 | 500 |
MPPT Operating Voltage Range (V) | 120-430 | 120-430 | 120-430 |
Start-up Voltage (V) | 150 | 150 | 150 |
Max.Input Current per MPPT(A) | 15 | 15 | 15 |
Number of MPPT Trackers | 2 | 2 | 2 |
AC Output Data (On-grid) | |||
Rated Power Output to Utility Grid (W) | 3600 | 4600 | 5000 |
Max. Apparent Power Output to Utility Grid (VA) | 3960 | 4600 | 5500 |
Max. Apparent Power from Utility Grid (VA) | 3960 | 4600 | 5500 |
Nominal Output Voltage (V) | 220 / 230 / 240 | 220 / 230 / 240 | 220 / 230 / 240 |
Nominal AC Grid Frequency (Hz) | 50/60 | 50/60 | 50/60 |
Max. AC Current Output to Utility Grid (A) | 17.2 | 20 | 23.9 |
Max. AC Current From Utility Grid (A) | 17.2 | 20 | 23.9 |
Power Factor | ~0.99 (Adiustable from 0.8 leading to 0.8 lagging) | ||
Switch Time | <10ms | <10ms | <10ms |
AC Output Data (Back-up) | |||
Back-up Rated Power(W) | 3600 | 4500 | 4500 |
Max. Output Apparent Power (VA) | 3600 | 4500 | 4500 |
Max. Output Current (A) | 15.6 | 20 | 20 |
Nominal Output Voltage (V) | 220 / 230 / 240 | 220 / 230 / 240 | 220 / 230 / 240 |
Nominal Output Freqency (Hz) | 50/60 | 50/60 | 50/60 |
Environmental / Ambient Conditions | |||
Operating Temperature Range (℃) | -25~+60 | ||
Excess Temperature Behaviour | Continuous power reduction (derating) | ||
Relative Humidity | 0 to 95 %,non-condensing | ||
Installation Altitude above Sea Level | up to 2000 m above sea level | ||
Installation Location | Inside & Outside | ||
Cooling Method | Natural Cooling | ||
Communications | |||
Communication with BMS | can | ||
Communication with Meter | RS485 | ||
Communication with Porta | WiFi | ||
Display | LED,WIFI+APP | ||
Monitoring Settings | Integrated data logger | ||
Reliability | |||
Manufacturer's Warranty | 5 Years | ||
Conversion Efficiency | |||
Max. Efficiency | 97.80% | ||
EU Efficiency | 97% | ||
Max. Battery to AC Efficiency | 95% | ||
MPPT Efficiency | 99.90% | ||
Mechanical Data | |||
Dimensions (W X H X D mm) | 350x580x230 | ||
Weight (kg) | 25±0.5 | ||
Protection Type | IP65 | ||
Other Data | |||
Topology | Transformer | ||
Self-consumption at Night (W) | <10 | ||
Protection | PV Insulation Resistance Detection, Residual Current Monitoring, Antiislanding Protection, AC Overcurrent Protection, AC Short Circuit Protection, AC Overvoltage Protection, DC Switch Remote Shutdown |
